Installing Draw.IO on Linux Ubuntu Laptop

All Linux Lessons
How do I install this software on my linux machine: It is available in following architectures: Linux - deb, AppImage or rpm

You can install draw.io (diagrams.net desktop) on Linux in three common ways. Pick the one that best fits your distro and preference.


✅ Option 1: DEB package (Best for Ubuntu / Linux Mint / Debian)

Recommended if you want system integration and automatic updates.

  1. Download the .deb file from the release page.

  2. Open a terminal in the download folder and run:

    bash
    sudo apt update sudo apt install ./drawio-amd64-29.0.3.deb

    Replace the filename if the version differs.

  3. Launch from the app menu or run:

    bash
    drawio

✅ Option 2: AppImage (Works on almost all distros)

No installation needed; great for portability.

  1. Download the .AppImage file.

  2. Make it executable:

    bash
    chmod +x drawio-29.0.3-x86_64.AppImage
  3. Run it:

    bash
    ./drawio-29.0.3-x86_64.AppImage

Optional: Move it to /opt and create a desktop shortcut if you want.


✅ Option 3: RPM package (Fedora / RHEL / openSUSE)

Use this if you’re on an RPM-based distro.

bash
sudo dnf install drawio-29.0.3.x86_64.rpm

or on openSUSE:

bash
sudo zypper install drawio-29.0.3.x86_64.rpm

🔍 Which should you choose?

  • Ubuntu / Linux Mint / DebianDEB

  • Any distro / portable useAppImage

  • Fedora / RHEL / openSUSERPM

If you tell me your exact distro (e.g., Ubuntu 22.04, Mint 21, Lubuntu, etc.), I’ll give you the exact filename and best command.

...
(base) jain@jain-ThinkPad-T440s:~/Downloads$ chmod +x drawio-x86_64-29.0.3.AppImage (base) jain@jain-ThinkPad-T440s:~/Downloads$ ./drawio-x86_64-29.0.3.AppImage dlopen(): error loading libfuse.so.2 AppImages require FUSE to run. You might still be able to extract the contents of this AppImage if you run it with the --appimage-extract option. See https://github.com/AppImage/AppImageKit/wiki/FUSE for more information

This is a very common AppImage issue 👍
Your system is missing FUSE v2 (libfuse.so.2), which AppImages require.

Let’s fix it cleanly.


✅ Fix 1 (Recommended): Install FUSE (libfuse2)

On Ubuntu / Linux Mint / Lubuntu:

bash
sudo apt update sudo apt install libfuse2

Then run again:

bash
./drawio-x86_64-29.0.3.AppImage

This should start draw.io immediately.


🔎 Why this happens

  • AppImages use FUSE (Filesystem in Userspace) to mount themselves.

  • Newer distros ship fuse3, but AppImages still expect fuse2.

  • Hence the missing libfuse.so.2.


🛠 Fix 2 (If you cannot install FUSE): Extract AppImage

If you’re on a restricted system:

bash
./drawio-x86_64-29.0.3.AppImage --appimage-extract

Then run it manually:

bash
cd squashfs-root ./drawio

⚠️ This works but no desktop integration.


🔁 Alternative (Most Stable): Install DEB instead

If you’re on Ubuntu/Mint/Lubuntu, the DEB version is simpler:

bash
sudo apt install ./drawio-amd64-29.0.3.deb

✅ Quick Recommendation

SituationBest Choice
Ubuntu / Mint / LubuntuDEB package
Portable / no installAppImage + libfuse2
Locked-down systemAppImage extract

If you want, I can:

  • Create a desktop launcher for the AppImage

  • Help you switch to the DEB version

  • Check if your system already has fuse3 vs fuse2

Just tell me 👍

... ... ...
(base) jain@jain-ThinkPad-T440s:~/Downloads$ ./drawio-x86_64-29.0.3.AppImage [6616:1227/063742.336623:FATAL:sandbox/linux/suid/client/setuid_sandbox_host.cc:166] The SUID sandbox helper binary was found, but is not configured correctly. Rather than run without sandboxing I'm aborting now. You need to make sure that /tmp/.mount_drawiodOPId7/chrome-sandbox is owned by root and has mode 4755. Trace/breakpoint trap (core dumped)

This is another very common Electron + AppImage issue 👍
Nothing is “broken” — it’s a sandbox permission problem.

The error means:

Electron found the chrome-sandbox helper inside the AppImage, but it cannot be setuid root, which is required for sandboxing.

Because AppImages run from /tmp/.mount_*, Linux does not allow setuid binaries there.


Fastest & Safest Fix (Recommended)

Run draw.io without the sandbox.

👉 Just run:

bash
./drawio-x86_64-29.0.3.AppImage --no-sandbox

This is safe for desktop apps like draw.io and is the official workaround.


🔁 Make it permanent (so you don’t type it every time)

Create a small wrapper:

bash
nano ~/bin/drawio

Paste:

bash
#!/bin/bash ~/Downloads/drawio-x86_64-29.0.3.AppImage --no-sandbox

Save (Ctrl+O, Enter, Ctrl+X) and make executable:

bash
chmod +x ~/bin/drawio

Now you can just run:

bash
drawio

🧠 Why this happens (short explanation)

  • draw.io is an Electron app (Chromium-based)

  • Chromium wants a setuid sandbox

  • AppImages mount under /tmp/.mount_*

  • Linux disallows setuid binaries there

  • Result → crash unless sandbox is disabled


🟢 Best Long-Term Solution (If you want zero issues)

Since you’re on Ubuntu/Mint/Lubuntu, the DEB package is better than AppImage:

bash
sudo apt install ./drawio-amd64-29.0.3.deb

✔ Proper sandbox
✔ Menu integration
✔ No flags needed
✔ Auto updates possible


🏁 Recommendation

MethodStability
AppImage + --no-sandbox✅ Works
AppImage without flag❌ Crashes
DEB package⭐⭐⭐⭐⭐ Best

If you want, I can:

  • Create a desktop icon for the AppImage

  • Help you switch cleanly to DEB

  • Explain security implications (briefly)

Just tell me 🙂
